CNC Plasma Cutting Machine
WUXI ABK’s CNC plasma cutting machine delivers high-speed, precision cutting for steel, pipes, and metal fabrication. Featuring multi-torch operation, automatic height control, and robust HIWIN rails, it ensures efficiency and accuracy in industries like oil, wind power, and automotive. Reliable plasma power supply and auto-ignition enhance productivity.
Product Overview
The CNC Plasma Cutting Machine represents a significant advancement in industrial metal fabrication technology. This high-precision cutting system delivers exceptional performance across various metal thicknesses, from delicate thin sheets to robust thick plates up to 50mm. Utilizing advanced plasma arc technology, the machine produces clean, efficient cuts on all conductive metals while maintaining tight tolerances of ±0.1mm/m. Its versatility makes it indispensable for critical industries including oil and gas infrastructure, pressure vessel manufacturing, and structural steel fabrication.
Technical Specifications
Our CNC plasma cutting systems feature cutting capabilities ranging from 0.5mm to 50mm thickness with maximum cutting speeds reaching 15m/min for thin materials. The machines are equipped with either Hypertherm or Haibao plasma power supplies, controlled by the industry-leading Siemens 840D sl CNC system. Operating on standard 380V±10% 50/60Hz power, these systems deliver reliable performance in demanding industrial environments while maintaining energy efficiency.
Cutting Performance and Features
The machine’s high-precision cutting performance stems from its advanced CNC control system that ensures accurate cutting paths and consistent results. Automatic torch height control maintains optimal cutting distance throughout operations, while the arc voltage height control (AVHC) system provides real-time adjustments for varying material conditions. The flexible configuration supports 1-3 plasma cutting torches with optional flame cutting compatibility, allowing for both synchronous and asynchronous cutting modes to maximize production efficiency.
Structural Design and Durability
Engineered for industrial longevity, the machine features an annealed steel frame that eliminates internal stresses and enhances structural stability. Precision-ground guide rails with mirror-polished surfaces (Ra0.8μm finish) ensure smooth operation throughout the machine’s service life. The triple-layer anti-corrosion coating system provides superior protection against rust and wear, even in harsh manufacturing environments, while the modular design simplifies maintenance and reduces downtime.
Intelligent Control and Safety Systems
The integrated control system combines German engineering precision with user-friendly operation. The 100% reliable auto-ignition function ensures consistent starts, while comprehensive overload protection safeguards the plasma power supply during operation. The intuitive interface allows operators to easily program complex cutting patterns and store frequently used parameters, with the system automatically optimizing cutting sequences for maximum efficiency.
Industrial Applications
These CNC plasma cutting machines excel in energy sector applications, producing precise components for oil and gas pipelines and pressure vessels. The technology is equally valuable for fabricating structural elements in wind power installations and creating architectural metalwork. Automotive and aerospace manufacturers benefit from the system’s ability to maintain material properties while producing complex components from various alloys. The combination of speed and precision significantly enhances productivity in structural steel fabrication for building frameworks and infrastructure projects.
Quality and Service Assurance
Each CNC plasma cutting machine undergoes rigorous quality control testing before delivery to ensure optimal performance. Our comprehensive service network provides prompt technical support and maintenance services worldwide. The systems are backed by an industry-leading warranty, with optional service contracts available for continuous performance monitoring and preventive maintenance. Custom training programs are offered to help operators maximize the machine’s capabilities and productivity.
Technical parameter
| Project | Technical indicators |
| Cutting accuracy | ≤±0.15mm/m |
| Maximum cutting speed | 15m/min |
| Operating voltage | 380V±10% 50/60Hz |
| Plasma power supply | Haibao /Hypertherm optional |
| Numerical control system | Siemens 840D sl |
| Operating ambient temperature | -10℃~45℃ |
Industry application case
Petroleum pipeline: X80 high-strength steel groove cutting
Wind power equipment: tower flange precision blanking
Pressure vessel: head curve cutting
Construction machinery: processing of high-strength steel components
Quality assurance
◇ 3-year warranty for key components
◇ Free operation training
◇ 24-month preventive maintenance plan
Technical Parameters of CNC Plasma Cutting Machine:
| Model | Driving form | Rail gap (mm) |
Effective width (mm) |
Cutting thickness(mm) | Cutting speed(mm/min) | Max speed (mm/min) | Vertical range (mm) | ||
| Flame cutting | Plasma cutting machine | Flame cutting | Plasma cutting | ||||||
| CNCⅠ-2500 | Single side | 2500 | 1600 | 6-200 (Refer to the performance of the cutting head) | Varies with different models | 100-750 (Refer to the performance of the cutting head) | Varies with the power supply | 6000 | 200 |
| CNCⅠ-3000 | Single side | 3500 | 2100 | 6000 | 200 | ||||
| CNCⅠ-4000 | Single side | 4000 | 3100 | 12000 | 200 | ||||
| CNCⅡ-4000 | Double side | 4000 | 3100 | 12000 | 200 | ||||
| CNCⅡ-5000 | Double side | 5000 | 4100 | 12000 | 200 | ||||
| CNCⅡ-6000 | Double side | 6000 | 5100 | 12000 | 200 | ||||
| CNCⅡ-7000 | Double side | 7000 | 6100 | 12000 | 200 | ||||
| CNCⅡ-8000 | Double side | 8000 | 7100 | 12000 | 200 | ||||
| CNCⅡ-9000 | Double side | 90000 | 8100 | 12000 | 200 | ||||
| CNCⅡ-11000 | Double side | 11000 | 10100 | 12000 | 200 | ||||
| CNCⅡ-12000 | Double side | 12000 | 11100 | 12000 | 200 | ||||
| CNCⅡ-13000 | Double side | 13000 | 12100 | 12000 | 200 | ||||
Technical Parameters of CNC Series Digital Multi-Head Straight Cutter:
| Model | Driving form | Rail gap (mm) | Effective width(mm) | Cutting thickness (mm) | Cutting speed (mm/min) | Max. speed (mm/min) | Vertical range (mm) |
| CNC-3000 | Single side | 3000 | 2100 | 6-200 (Refer to the performance of the cutting head) | 100-750 (Refer to the performance of the cutting head) | 6000 | 150 |
| CNC-3500 | Single side | 3500 | 2600 | 6000 | 150 | ||
| CNC-4000 | Single side | 4000 | 3100 | 12000 | 150 | ||
| CNCⅡ-5000 | Double side | 5000 | 4100 | 12000 | 150 | ||
| CNCⅡ-6000 | Double side | 6000 | 5100 | 12000 | 150 | ||
| CNCⅡ-7000 | Double side | 7000 | 6100 | 12000 | 150 | ||
| CNCⅡ-8000 | Double side | 8000 | 7100 | 12000 | 150 | ||
| CNCⅡ-9000 | Double side | 9000 | 8100 | 12000 | 150 | ||
| CNCⅡ-10000 | Double side | 10000 | 9000 | 12000 | 150 | ||
| CNCⅡ-11000 | Double side | 11000 | 10100 | 12000 | 150 | ||
| CNCⅡ-12000 | Double side | 12000 | 11100 | 12000 | 150 | ||
| CNCⅡ-13000 | Double side | 13000 | 12100 | 12000 | 150 |
